MMDF3N02HDR2 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 20V 3.8A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MMDF3N02HDR2 Specifications:
- MfrPart.: MMDF3N02HDR2
- Mfr: onsemi
- Description: MOSFET N-CH 20V 3.8A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 3.8A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 90mOhm @ 3A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 18 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 630 pF @ 16 V
- FETFeature: -
- PowerDissipation(Max): 2W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- MMDF3N02HDR2 onsemi (ON), MOSFET N-CH 20V 3.8A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
MMDF3N02HDR2, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
