MMBT3702 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-236-3, SC-59, SOT-23-3
- Description: TRANS PNP 25V 0.8A SOT-23
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MMBT3702 Specifications:
- MfrPart.: MMBT3702
- Mfr: onsemi
- Description: TRANS PNP 25V 0.8A SOT-23
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 800 mA
- Voltage-CollectorEmitterBreakdown(Max): 25 V
- VceSaturation(Max)@IbIc: 250mV @ 5mA, 50mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 60 @ 50mA, 5V
- Power-Max: 350 mW
- Frequency-Transition: 100MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-236-3, SC-59, SOT-23-3
- MMBT3702 onsemi (ON), TRANS PNP 25V 0.8A SOT-23, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
MMBT3702, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
