MJE701STU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
- Description: TRANS PNP DARL 60V 4A TO126
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MJE701STU Specifications:
- MfrPart.: MJE701STU
- Mfr: onsemi
- Description: TRANS PNP DARL 60V 4A TO126
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP - Darlington
- Current-Collector(Ic)(Max): 4 A
- Voltage-CollectorEmitterBreakdown(Max): 60 V
- VceSaturation(Max)@IbIc: 2.8V @ 40mA, 2A
- Current-CollectorCutoff(Max): 100µA
- DCCurrentGain(hFE)(Min)@IcVce: 750 @ 2A, 3V
- Power-Max: 40 W
- Frequency-Transition: -
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-225AA, TO-126-3
- MJE701STU onsemi (ON), TRANS PNP DARL 60V 4A TO126, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
MJE701STU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
