MGSF2N02ELT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3 (TO-236)
- Description: MOSFET N-CH 20V 2.8A SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MGSF2N02ELT1G Specifications:
- MfrPart.: MGSF2N02ELT1G
- Mfr: onsemi
- Description: MOSFET N-CH 20V 2.8A SOT23-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 2.8A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 85mOhm @ 3.6A, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 3.5 nC @ 4 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 150 pF @ 5 V
- FETFeature: -
- PowerDissipation(Max): 1.25W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-3 (TO-236)
- MGSF2N02ELT1G onsemi (ON), MOSFET N-CH 20V 2.8A SOT23-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
