MGP15N40CLG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 440V 15A 150W TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MGP15N40CLG Specifications:
- MfrPart.: MGP15N40CLG
- Mfr: onsemi
- Description: IGBT 440V 15A 150W TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 440 V
- Current-Collector(Ic)(Max): 15 A
- Current-CollectorPulsed(Icm): 50 A
- Vce(on)(Max)@VgeIc: 2.9V @ 4V, 25A
- Power-Max: 150 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: -
- Td(on/off)@25°C: -/4µs
- TestCondition: 300V, 6.5A, 1kOhm
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- MGP15N40CLG onsemi (ON), IGBT 440V 15A 150W TO220AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
