MGP15N40CL onsemi IGBT 440V 15A 150W TO220AB
MGP15N40CL Images
MGP15N40CL Images
MGP15N40CL
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
  • Description: IGBT 440V 15A 150W TO220AB
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MGP15N40CL Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MGP15N40CL Specifications:
  • MfrPart.: MGP15N40CL
  • Mfr: onsemi
  • Description: IGBT 440V 15A 150W TO220AB
  • Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • IGBTType: -
  • Voltage-CollectorEmitterBreakdown(Max): 440 V
  • Current-Collector(Ic)(Max): 15 A
  • Current-CollectorPulsed(Icm): 50 A
  • Vce(on)(Max)@VgeIc: 2.9V @ 4V, 25A
  • Power-Max: 150 W
  • SwitchingEnergy: -
  • InputType: Logic
  • GateCharge: -
  • Td(on/off)@25°C: -/4µs
  • TestCondition: 300V, 6.5A, 1kOhm
  • ReverseRecoveryTime(trr): -
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-220-3
  • MGP15N40CL onsemi (ON), IGBT 440V 15A 150W TO220AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
