MCH3383-TL-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-70FL/MCPH3
- Description: MOSFET P-CH 12V 3.5A SC70
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MCH3383-TL-H Specifications:
- MfrPart.: MCH3383-TL-H
- Mfr: onsemi
- Description: MOSFET P-CH 12V 3.5A SC70
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 12 V
- Current-ContinuousDrain(Id)@25°C: 3.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 0.9V, 2.5V
- RdsOn(Max)@IdVgs: 69mOhm @ 1.5A, 2.5V
- Vgs(th)(Max)@Id: 800mV @ 1mA
- GateCharge(Qg)(Max)@Vgs: 6.2 nC @ 2.5 V
- Vgs(Max): ±5V
- InputCapacitance(Ciss)(Max)@Vds: 1010 pF @ 6 V
- FETFeature: -
- PowerDissipation(Max): 1W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TA)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-70FL/MCPH3
- MCH3383-TL-H onsemi (ON), MOSFET P-CH 12V 3.5A SC70, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
MCH3383-TL-H, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
