MC7815ACTG Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: TO-220-3
- Description: IC REG LINEAR 15V 1A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MC7815ACTG Specifications:
- MfrPart.: MC7815ACTG
- Mfr: onsemi
- Description: IC REG LINEAR 15V 1A TO220AB
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tube
- Series: -
- PartStatus: Active
- OutputConfiguration: Positive
- OutputType: Fixed
- NumberofRegulators: 1
- Voltage-Input(Max): 35V
- Voltage-Output(Min/Fixed): 15V
- Voltage-Output(Max): -
- VoltageDropout(Max): 2V @ 1A (Typ)
- Current-Output: 1A
- Current-Quiescent(Iq): 6 mA
- Current-Supply(Max): -
- PSRR: 80dB (120Hz)
- ControlFeatures: -
- ProtectionFeatures: Over Temperature, Short Circuit
- OperatingTemperature: 0°C ~ 125°C
- MountingType: Through Hole
- Package/Case: TO-220-3
- MC7815ACTG onsemi (ON), IC REG LINEAR 15V 1A TO220AB, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
MC7815ACTG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
