MC74HC4053ANG Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC MUX/DEMUX TRIPLE 2X1 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MC74HC4053ANG Specifications:
- MfrPart.: MC74HC4053ANG
- Mfr: onsemi
- Description: IC MUX/DEMUX TRIPLE 2X1 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 3
- On-StateResistance(Max): 100Ohm
- Channel-to-ChannelMatching(ΔRon): 10Ohm
- Voltage-SupplySingle(V+): 2V ~ 6V
- Voltage-SupplyDual(V±): ±2V ~ 6V
- SwitchTime(TonToff)(Max): -
- -3dbBandwidth: 120MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 50pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -60dB @ 1MHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- MC74HC4053ANG onsemi (ON), IC MUX/DEMUX TRIPLE 2X1 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MC74HC4053ANG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
