MC14052BDG Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: IC MUX/DEMUX DUAL 4X1 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MC14052BDG Specifications:
- MfrPart.: MC14052BDG
- Mfr: onsemi
- Description: IC MUX/DEMUX DUAL 4X1 16SOIC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: DP4T
- Multiplexer/DemultiplexerCircuit: 2:4
- NumberofCircuits: 2
- On-StateResistance(Max): 280Ohm
- Channel-to-ChannelMatching(ΔRon): 10Ohm
- Voltage-SupplySingle(V+): 3V ~ 18V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): -
- -3dbBandwidth: 17MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 7.5pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- MC14052BDG onsemi (ON), IC MUX/DEMUX DUAL 4X1 16SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MC14052BDG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
