KSD569RTU onsemi TRANS NPN 80V 7A TO-220
KSD569RTU Images
KSD569RTU Images
KSD569RTU
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-220-3
  • Description: TRANS NPN 80V 7A TO-220
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
KSD569RTU Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
KSD569RTU Specifications:
  • MfrPart.: KSD569RTU
  • Mfr: onsemi
  • Description: TRANS NPN 80V 7A TO-220
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 7 A
  • Voltage-CollectorEmitterBreakdown(Max): 80 V
  • VceSaturation(Max)@IbIc: 500mV @ 500mA, 5A
  • Current-CollectorCutoff(Max): 10µA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 40 @ 3A, 1V
  • Power-Max: 1.5 W
  • Frequency-Transition: -
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-220-3
  • KSD569RTU onsemi (ON), TRANS NPN 80V 7A TO-220, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
