KSC2223YMTF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-236-3, SC-59, SOT-23-3
- Description: TRANS NPN 20V 20MA SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
KSC2223YMTF Specifications:
- MfrPart.: KSC2223YMTF
- Mfr: onsemi
- Description: TRANS NPN 20V 20MA SOT23-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 20 mA
- Voltage-CollectorEmitterBreakdown(Max): 20 V
- VceSaturation(Max)@IbIc: 300mV @ 1mA, 10mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 90 @ 1mA, 6V
- Power-Max: 150 mW
- Frequency-Transition: 600MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-236-3, SC-59, SOT-23-3
- KSC2223YMTF onsemi (ON), TRANS NPN 20V 20MA SOT23-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
KSC2223YMTF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
