KSA1298PYWD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-236-3, SC-59, SOT-23-3
- Description: TRANS PNP 25V 0.8A SOT-23
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
KSA1298PYWD Specifications:
- MfrPart.: KSA1298PYWD
- Mfr: onsemi
- Description: TRANS PNP 25V 0.8A SOT-23
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 800 mA
- Voltage-CollectorEmitterBreakdown(Max): 25 V
- VceSaturation(Max)@IbIc: 400mV @ 20mA, 500mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 100mA, 1V
- Power-Max: 200 mW
- Frequency-Transition: 120MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-236-3, SC-59, SOT-23-3
- KSA1298PYWD onsemi (ON), TRANS PNP 25V 0.8A SOT-23, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
