J109 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - JFETs Package/Case: TO-226-3, TO-92-3 (TO-226AA)
- Description: JFET N-CH 25V 625MW TO92
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
J109 Specifications:
- MfrPart.: J109
- Mfr: onsemi
- Description: JFET N-CH 25V 625MW TO92
- Product Category: Discrete Semiconductor Products~Transistors - JFETs
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Voltage-Breakdown(V(BR)GSS): 25 V
- DraintoSourceVoltage(Vdss): -
- Current-Drain(Idss)@Vds(Vgs=0): 40 mA @ 15 V
- CurrentDrain(Id)-Max: -
- Voltage-Cutoff(VGSoff)@Id: 2 V @ 10 nA
- InputCapacitance(Ciss)(Max)@Vds: -
- Resistance-RDS(On): 12 Ohms
- Power-Max: 625 mW
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 (TO-226AA)
- J109 onsemi (ON), JFET N-CH 25V 625MW TO92, Discrete Semiconductor Products~Transistors - JFETs
