ISL9V5036S3 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- Description: N-CHANNEL IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISL9V5036S3 Specifications:
- MfrPart.: ISL9V5036S3
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: N-CHANNEL IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: EcoSPARK®
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 390 V
- Current-Collector(Ic)(Max): 46 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 1.6V @ 4V, 10A
- Power-Max: 250 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: 32 nC
- Td(on/off)@25°C: -/10.8µs
- TestCondition: 300V, 1kOhm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- ISL9V5036S3 onsemi (ON), N-CHANNEL IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
ISL9V5036S3, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
