ISL9V3036S3ST Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 360V 21A TO263AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISL9V3036S3ST Specifications:
- MfrPart.: ISL9V3036S3ST
- Mfr: onsemi
- Description: IGBT 360V 21A TO263AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: EcoSPARK®
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 360 V
- Current-Collector(Ic)(Max): 21 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 1.6V @ 4V, 6A
- Power-Max: 150 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: 17 nC
- Td(on/off)@25°C: -/4.8µs
- TestCondition: 300V, 1kOhm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- ISL9V3036S3ST onsemi (ON), IGBT 360V 21A TO263AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
ISL9V3036S3ST, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
