ISL9N302AS3 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I2PAK (TO-262)
- Description: MOSFET N-CH 30V 75A TO-262AA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISL9N302AS3 Specifications:
- MfrPart.: ISL9N302AS3
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: MOSFET N-CH 30V 75A TO-262AA
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: UltraFET™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 75A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.3mOhm @ 75A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 300 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 11 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 345W (Tc)
- OperatingTemperature: -
- MountingType: Through Hole
- SupplierDevicePackage: I2PAK (TO-262)
- ISL9N302AS3 onsemi (ON), MOSFET N-CH 30V 75A TO-262AA, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
