ISL9K1560G3 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-247-3
- Description: DIODE ARRAY GP 600V 15A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISL9K1560G3 Specifications:
- Mfr Part: ISL9K1560G3
- Mfr: onsemi
- Description: DIODE ARRAY GP 600V 15A TO247
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Tube
- Series: Stealth™
- Part Status: Obsolete
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600 V
- Current - Average Rectified (Io) (per Diode): 15A
- Voltage - Forward (Vf) (Max) @ If: 2.2 V @ 15 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 100 µA @ 600 V
- Operating Temperature - Junction: -55°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- ISL9K1560G3 onsemi (ON), DIODE ARRAY GP 600V 15A TO247, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
ISL9K1560G3, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
