IRLR230ATF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET N-CH 200V 7.5A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLR230ATF Specifications:
- MfrPart.: IRLR230ATF
- Mfr: onsemi
- Description: MOSFET N-CH 200V 7.5A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 200 V
- Current-ContinuousDrain(Id)@25°C: 7.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V
- RdsOn(Max)@IdVgs: 400mOhm @ 3.75A, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 27 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 755 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 48W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- IRLR230ATF onsemi (ON), MOSFET N-CH 200V 7.5A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRLR230ATF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
