IRLM220ATF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223-4
- Description: MOSFET N-CH 200V 1.13A SOT223-4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLM220ATF Specifications:
- MfrPart.: IRLM220ATF
- Mfr: onsemi
- Description: MOSFET N-CH 200V 1.13A SOT223-4
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 200 V
- Current-ContinuousDrain(Id)@25°C: 1.13A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V
- RdsOn(Max)@IdVgs: 800mOhm @ 570mA, 5V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 15 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 430 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223-4
- IRLM220ATF onsemi (ON), MOSFET N-CH 200V 1.13A SOT223-4, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRLM220ATF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
