IMH20TR1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: SC-74, SOT-457
- Description: TRANS PREBIAS 2NPN 15V SC74R
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IMH20TR1G Specifications:
- MfrPart.: IMH20TR1G
- Mfr: onsemi
- Description: TRANS PREBIAS 2NPN 15V SC74R
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- TransistorType: 2 NPN - Pre-Biased (Dual)
- Current-Collector(Ic)(Max): 600mA
- Voltage-CollectorEmitterBreakdown(Max): 15V
- Resistor-Base(R1): 2.2kOhms
- Resistor-EmitterBase(R2): -
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 50mA, 5V
- VceSaturation(Max)@IbIc: 80mV @ 2.5mA, 50mA
- Current-CollectorCutoff(Max): -
- Frequency-Transition: -
- Power-Max: 300mW
- MountingType: Surface Mount
- Package/Case: SC-74, SOT-457
- IMH20TR1G onsemi (ON), TRANS PREBIAS 2NPN 15V SC74R, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
IMH20TR1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
