IMD10AMT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: SC-74, SOT-457
- Description: TRANS NPN/PNP PREBIAS SC74R
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IMD10AMT1G Specifications:
- MfrPart.: IMD10AMT1G
- Mfr: onsemi
- Description: TRANS NPN/PNP PREBIAS SC74R
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: 1 NPN, 1 PNP - Pre-Biased (Dual)
- Current-Collector(Ic)(Max): 500mA
- Voltage-CollectorEmitterBreakdown(Max): 50V
- Resistor-Base(R1): 13kOhms, 130Ohms
- Resistor-EmitterBase(R2): 10kOhms
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 1mA, 5V / 68 @ 100mA, 5V
- VceSaturation(Max)@IbIc: 300mV @ 1mA, 10mA
- Current-CollectorCutoff(Max): 500nA
- Frequency-Transition: -
- Power-Max: 285mW
- MountingType: Surface Mount
- Package/Case: SC-74, SOT-457
- IMD10AMT1G onsemi (ON), TRANS NPN/PNP PREBIAS SC74R, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
IMD10AMT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
