HUF75545S3 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I2PAK (TO-262)
- Description: MOSFET N-CH 80V 75A I2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HUF75545S3 Specifications:
- MfrPart.: HUF75545S3
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: MOSFET N-CH 80V 75A I2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: UltraFET™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 80 V
- Current-ContinuousDrain(Id)@25°C: 75A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 10mOhm @ 75A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 235 nC @ 20 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3.75 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 270W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I2PAK (TO-262)
- HUF75545S3 onsemi (ON), MOSFET N-CH 80V 75A I2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
HUF75545S3, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
