HGTP7N60A4-F102 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT, 600V, SMPS
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGTP7N60A4-F102 Specifications:
- MfrPart.: HGTP7N60A4-F102
- Mfr: onsemi
- Description: IGBT, 600V, SMPS
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 34 A
- Current-CollectorPulsed(Icm): 56 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 7A
- Power-Max: 125 W
- SwitchingEnergy: 55µJ (on), 150µJ (off)
- InputType: Standard
- GateCharge: 60 nC
- Td(on/off)@25°C: 11ns/100ns
- TestCondition: 390V, 7A, 25Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- HGTP7N60A4-F102 onsemi (ON), IGBT, 600V, SMPS, Discrete Semiconductor Products~Transistors - IGBTs - Single
