HGTP12N60C3D Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 24A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGTP12N60C3D Specifications:
- MfrPart.: HGTP12N60C3D
- Mfr: onsemi
- Description: IGBT 600V 24A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 24 A
- Current-CollectorPulsed(Icm): 96 A
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 15A
- Power-Max: 104 W
- SwitchingEnergy: 380µJ (on), 900µJ (off)
- InputType: Standard
- GateCharge: 48 nC
- Td(on/off)@25°C: -
- TestCondition: -
- ReverseRecoveryTime(trr): 40 ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- HGTP12N60C3D onsemi (ON), IGBT 600V 24A TO220-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
HGTP12N60C3D, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
