HGTG40N60A4 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 75A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGTG40N60A4 Specifications:
- MfrPart.: HGTG40N60A4
- Mfr: onsemi
- Description: IGBT 600V 75A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube,Tube
- Series: -
- PartStatus: Not For New Designs
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 75 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 40A
- Power-Max: 625 W
- SwitchingEnergy: 400µJ (on), 370µJ (off)
- InputType: Standard
- GateCharge: 350 nC
- Td(on/off)@25°C: 25ns/145ns
- TestCondition: 390V, 40A, 2.2Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- HGTG40N60A4 onsemi (ON), IGBT 600V 75A TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
