HGTD1N120BNS9A onsemi IGBT 1200V 5.3A 60W TO252AA
HGTD1N120BNS9A Images
HGTD1N120BNS9A Images
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Description: IGBT 1200V 5.3A 60W TO252AA
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
HGTD1N120BNS9A Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
HGTD1N120BNS9A Specifications:
  • MfrPart.: HGTD1N120BNS9A
  • Mfr: onsemi
  • Description: IGBT 1200V 5.3A 60W TO252AA
  • Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • IGBTType: NPT
  • Voltage-CollectorEmitterBreakdown(Max): 1200 V
  • Current-Collector(Ic)(Max): 5.3 A
  • Current-CollectorPulsed(Icm): 6 A
  • Vce(on)(Max)@VgeIc: 2.9V @ 15V, 1A
  • Power-Max: 60 W
  • SwitchingEnergy: 70µJ (on), 90µJ (off)
  • InputType: Standard
  • GateCharge: 14 nC
  • Td(on/off)@25°C: 15ns/67ns
  • TestCondition: 960V, 1A, 82Ohm, 15V
  • ReverseRecoveryTime(trr): -
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • HGTD1N120BNS9A onsemi (ON), IGBT 1200V 5.3A 60W TO252AA, Discrete Semiconductor Products~Transistors - IGBTs - Single
