HGT1S7N60A4DS Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 600V 34A 125W TO263AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGT1S7N60A4DS Specifications:
- MfrPart.: HGT1S7N60A4DS
- Mfr: onsemi
- Description: IGBT 600V 34A 125W TO263AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 34 A
- Current-CollectorPulsed(Icm): 56 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 7A
- Power-Max: 125 W
- SwitchingEnergy: 55µJ (on), 60µJ (off)
- InputType: Standard
- GateCharge: 37 nC
- Td(on/off)@25°C: 11ns/100ns
- TestCondition: 390V, 7A, 25Ohm, 15V
- ReverseRecoveryTime(trr): 34 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- HGT1S7N60A4DS onsemi (ON), IGBT 600V 34A 125W TO263AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
HGT1S7N60A4DS, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
