HGT1S3N60A4DS9A Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 600V 17A 70W D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGT1S3N60A4DS9A Specifications:
- MfrPart.: HGT1S3N60A4DS9A
- Mfr: onsemi
- Description: IGBT 600V 17A 70W D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 17 A
- Current-CollectorPulsed(Icm): 40 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 3A
- Power-Max: 70 W
- SwitchingEnergy: 37µJ (on), 25µJ (off)
- InputType: Standard
- GateCharge: 21 nC
- Td(on/off)@25°C: 6ns/73ns
- TestCondition: 390V, 3A, 50Ohm, 15V
- ReverseRecoveryTime(trr): 29 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- HGT1S3N60A4DS9A onsemi (ON), IGBT 600V 17A 70W D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
