HGT1S2N120CN Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- Description: N-CHANNEL IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGT1S2N120CN Specifications:
- MfrPart.: HGT1S2N120CN
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: N-CHANNEL IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1.2 kV
- Current-Collector(Ic)(Max): 13 A
- Current-CollectorPulsed(Icm): 20 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 2.6A
- Power-Max: 104 W
- SwitchingEnergy: 96µJ (on), 355µJ (off)
- InputType: Standard
- GateCharge: 30 nC
- Td(on/off)@25°C: 25ns/205ns
- TestCondition: 960V, 2.6A, 51Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- HGT1S2N120CN onsemi (ON), N-CHANNEL IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
