HCPL3700 Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 8-DIP (0.300, 7.62mm)
- Description: OPTOISO 2.5KV DARLINGTON 8-DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HCPL3700 Specifications:
- MfrPart.: HCPL3700
- Mfr: onsemi
- Description: OPTOISO 2.5KV DARLINGTON 8-DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 2500Vrms
- CurrentTransferRatio(Min): -
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 6µs, 25µs
- Rise/FallTime(Typ): 45µs, 0.5µs
- InputType: AC, DC
- OutputType: Darlington
- Voltage-Output(Max): 20V
- Current-Output/Channel: 30mA
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- VceSaturation(Max): -
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- HCPL3700 onsemi (ON), OPTOISO 2.5KV DARLINGTON 8-DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
HCPL3700, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
