HCPL2631M onsemi OPTOISO 5KV 2CH OPEN COLL 8DIP
HCPL2631M Images
HCPL2631M Images
HCPL2631M
  • Manufacturer: onsemi (ON)
  • Category: Isolators~Optoisolators - Logic Output Package/Case: 8-DIP (0.300, 7.62mm)
  • Description: OPTOISO 5KV 2CH OPEN COLL 8DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
HCPL2631M Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
HCPL2631M Specifications:
  • MfrPart.: HCPL2631M
  • Mfr: onsemi
  • Description: OPTOISO 5KV 2CH OPEN COLL 8DIP
  • Product Category: Isolators~Optoisolators - Logic Output
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • NumberofChannels: 2
  • Inputs-Side1/Side2: 2/0
  • Voltage-Isolation: 5000Vrms
  • CommonModeTransientImmunity(Min): 5kV/µs
  • InputType: DC
  • OutputType: Open Collector
  • Current-Output/Channel: 25 mA
  • DataRate: 10Mbps
  • PropagationDelaytpLH/tpHL(Max): 75ns, 75ns
  • Rise/FallTime(Typ): 30ns, 10ns
  • Voltage-Forward(Vf)(Typ): 1.45V
  • Current-DCForward(If)(Max): 30mA
  • Voltage-Supply: 4.5V ~ 5.5V
  • OperatingTemperature: -40°C ~ 110°C
  • MountingType: Through Hole
  • Package/Case: 8-DIP (0.300, 7.62mm)
  • HCPL2631M onsemi (ON), OPTOISO 5KV 2CH OPEN COLL 8DIP, Isolators~Optoisolators - Logic Output
