HCPL0701 Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: OPTOCOUPLER DARL OUT 1CH 8-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HCPL0701 Specifications:
- MfrPart.: HCPL0701
- Mfr: onsemi
- Description: OPTOCOUPLER DARL OUT 1CH 8-SOIC
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 2500Vrms
- CurrentTransferRatio(Min): 500% @ 1.6mA
- CurrentTransferRatio(Max): 2600% @ 1.6mA
- TurnOn/TurnOffTime(Typ): 300ns, 1.6µs
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Darlington with Base
- Voltage-Output(Max): 18V
- Current-Output/Channel: 60mA
- Voltage-Forward(Vf)(Typ): 1.25V
- Current-DCForward(If)(Max): 20 mA
- VceSaturation(Max): -
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- HCPL0701 onsemi (ON), OPTOCOUPLER DARL OUT 1CH 8-SOIC, Isolators~Optoisolators - Transistor, Photovoltaic Output
HCPL0701, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
