HCPL062NR1 Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Logic Output Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: OPTOISO 2.5KV 2CH OPEN COLL 8SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HCPL062NR1 Specifications:
- MfrPart.: HCPL062NR1
- Mfr: onsemi
- Description: OPTOISO 2.5KV 2CH OPEN COLL 8SO
- Product Category: Isolators~Optoisolators - Logic Output
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 2
- Inputs-Side1/Side2: 2/0
- Voltage-Isolation: 2500Vrms
- CommonModeTransientImmunity(Min): 25kV/µs
- InputType: DC
- OutputType: Open Collector
- Current-Output/Channel: 15 mA
- DataRate: 10Mbps
- PropagationDelaytpLH/tpHL(Max): 90ns, 75ns
- Rise/FallTime(Typ): 16ns, 4ns
- Voltage-Forward(Vf)(Typ): 1.75V (Max)
- Current-DCForward(If)(Max): 50mA
- Voltage-Supply: 2.7V ~ 3.3V
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- HCPL062NR1 onsemi (ON), OPTOISO 2.5KV 2CH OPEN COLL 8SO, Isolators~Optoisolators - Logic Output
HCPL062NR1, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
