HCPL0501V Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: OPTOCOUPLER SGL TRANS OUT 8-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HCPL0501V Specifications:
- MfrPart.: HCPL0501V
- Mfr: onsemi
- Description: OPTOCOUPLER SGL TRANS OUT 8-SOIC
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 2500Vrms
- CurrentTransferRatio(Min): 19% @ 16mA
- CurrentTransferRatio(Max): 50% @ 16mA
- TurnOn/TurnOffTime(Typ): 450ns, 300ns
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Transistor with Base
- Voltage-Output(Max): 20V
- Current-Output/Channel: 8mA
- Voltage-Forward(Vf)(Typ): 1.45V
- Current-DCForward(If)(Max): 25 mA
- VceSaturation(Max): -
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- HCPL0501V onsemi (ON), OPTOCOUPLER SGL TRANS OUT 8-SOIC, Isolators~Optoisolators - Transistor, Photovoltaic Output
HCPL0501V, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
