H11L1SR2M_F132 Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Logic Output Package/Case: 6-SMD, Gull Wing
- Description: OPTOISO 4.17KV OPN COLL 6SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
H11L1SR2M_F132 Specifications:
- MfrPart.: H11L1SR2M_F132
- Mfr: onsemi
- Description: OPTOISO 4.17KV OPN COLL 6SMD
- Product Category: Isolators~Optoisolators - Logic Output
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Inputs-Side1/Side2: 1/0
- Voltage-Isolation: 4170Vrms
- CommonModeTransientImmunity(Min): -
- InputType: DC
- OutputType: Open Collector
- Current-Output/Channel: 50 mA
- DataRate: 1MHz
- PropagationDelaytpLH/tpHL(Max): 4µs, 4µs
- Rise/FallTime(Typ): 100ns, 100ns
- Voltage-Forward(Vf)(Typ): 1.2V
- Current-DCForward(If)(Max): 30mA
- Voltage-Supply: 3V ~ 15V
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 6-SMD, Gull Wing
- H11L1SR2M_F132 onsemi (ON), OPTOISO 4.17KV OPN COLL 6SMD, Isolators~Optoisolators - Logic Output
H11L1SR2M_F132, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
