H11B1300 Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-DIP (0.300, 7.62mm)
- Description: DARLINGTON OUTPUT OPTOCOUPLER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
H11B1300 Specifications:
- MfrPart.: H11B1300
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: DARLINGTON OUTPUT OPTOCOUPLER
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Voltage-Isolation: 5300Vrms
- CurrentTransferRatio(Min): 500% @ 1mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 25µs, 18µs
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Darlington with Base
- Voltage-Output(Max): 25V
- Current-Output/Channel: -
- Voltage-Forward(Vf)(Typ): 1.2V
- Current-DCForward(If)(Max): 100 mA
- VceSaturation(Max): 1V
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Through Hole
- Package/Case: 6-DIP (0.300, 7.62mm)
- H11B1300 onsemi (ON), DARLINGTON OUTPUT OPTOCOUPLER, Isolators~Optoisolators - Transistor, Photovoltaic Output
H11B1300, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
