FQPF7N80C Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220F-3
- Description: MOSFET N-CH 800V 6.6A TO220F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FQPF7N80C Specifications:
- MfrPart.: FQPF7N80C
- Mfr: onsemi
- Description: MOSFET N-CH 800V 6.6A TO220F
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: QFET®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 6.6A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.9Ohm @ 3.3A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 35 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1680 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 56W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220F-3
- FQPF7N80C onsemi (ON), MOSFET N-CH 800V 6.6A TO220F, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FQPF7N80C, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
