FQPF3N80CYDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220F-3 (Y-Forming)
- Description: MOSFET N-CH 800V 3A TO220F-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FQPF3N80CYDTU Specifications:
- MfrPart.: FQPF3N80CYDTU
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: MOSFET N-CH 800V 3A TO220F-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: QFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 3A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 4.8Ohm @ 1.5A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 16.5 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 705 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 39W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220F-3 (Y-Forming)
- FQPF3N80CYDTU onsemi (ON), MOSFET N-CH 800V 3A TO220F-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
