FQPF30N06L Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220F-3
- Description: MOSFET N-CH 60V 22.5A TO220F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FQPF30N06L Specifications:
- MfrPart.: FQPF30N06L
- Mfr: onsemi
- Description: MOSFET N-CH 60V 22.5A TO220F
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: QFET®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 22.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 35mOhm @ 11.3A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 20 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1040 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 38W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220F-3
- FQPF30N06L onsemi (ON), MOSFET N-CH 60V 22.5A TO220F, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FQPF30N06L, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
