FQD20N06TM Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET N-CH 60V 16.8A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FQD20N06TM Specifications:
- MfrPart.: FQD20N06TM
- Mfr: onsemi
- Description: MOSFET N-CH 60V 16.8A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: QFET®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 16.8A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 63mOhm @ 8.4A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 15 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 590 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 38W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- FQD20N06TM onsemi (ON), MOSFET N-CH 60V 16.8A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FQD20N06TM, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
