FODM2701R4 Images

Manufacturer: onsemi (ON)
Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-SMD, Gull Wing
Description: OPTOCOUPLER PHOTOTRANS MFP4
COMPETITIVE PRICE and DELIVERY TIME
Order with confidence, there are no lead times for in-stock products.

Download Datasheet (PDF)

FODM2701R4 Specifications:

MfrPart.: FODM2701R4
Mfr: onsemi
Description: OPTOCOUPLER PHOTOTRANS MFP4
Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
Package: Tape & Reel (TR)
Series: -
PartStatus: Active
NumberofChannels: 1
Voltage-Isolation: 3750Vrms
CurrentTransferRatio(Min): 50% @ 5mA
CurrentTransferRatio(Max): 300% @ 5mA
TurnOn/TurnOffTime(Typ): -
Rise/FallTime(Typ): 3µs, 3µs
InputType: DC
OutputType: Transistor
Voltage-Output(Max): 40V
Current-Output/Channel: 80mA
Voltage-Forward(Vf)(Typ): 1.4V (Max)
Current-DCForward(If)(Max): 50 mA
VceSaturation(Max): 300mV
OperatingTemperature: -40°C ~ 110°C
MountingType: Surface Mount
Package/Case: 4-SMD, Gull Wing
FODM2701R4 onsemi (ON), OPTOCOUPLER PHOTOTRANS MFP4, Isolators~Optoisolators - Transistor, Photovoltaic Output
