FOD3120TSR2 Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 8-SMD, Gull Wing
- Description: OPTOISO 5KV GATE DRIVER 8SMDIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FOD3120TSR2 Specifications:
- MfrPart.: FOD3120TSR2
- Mfr: onsemi
- Description: OPTOISO 5KV GATE DRIVER 8SMDIP
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: OPTOPLANAR®
- PartStatus: Not For New Designs
- Technology: Optical Coupling
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): 35kV/µs
- PropagationDelaytpLH/tpHL(Max): 400ns, 400ns
- PulseWidthDistortion(Max): 100ns
- Rise/FallTime(Typ): 60ns, 60ns
- Current-OutputHighLow: 2A, 2A
- Current-PeakOutput: 3A
- Voltage-Forward(Vf)(Typ): 1.5V
- Current-DCForward(If)(Max): 25 mA
- Voltage-OutputSupply: 15V ~ 30V
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 8-SMD, Gull Wing
- FOD3120TSR2 onsemi (ON), OPTOISO 5KV GATE DRIVER 8SMDIP, Isolators~Isolators - Gate Drivers
