FMS7G20US60 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: 25PM-AA
- Description: IGBT MODULE 600V 20A 89W 25PMAA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FMS7G20US60 Specifications:
- MfrPart.: FMS7G20US60
- Mfr: onsemi
- Description: IGBT MODULE 600V 20A 89W 25PMAA
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Box
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Configuration: Three Phase Inverter with Brake
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 20 A
- Power-Max: 89 W
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 20A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 1.277 nF @ 30 V
- Input: Three Phase Bridge Rectifier
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: 25PM-AA
- FMS7G20US60 onsemi (ON), IGBT MODULE 600V 20A 89W 25PMAA, Discrete Semiconductor Products~Transistors - IGBTs - Modules
