FMG2G75US120 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: 7PM-GA
- Description: IGBT MODULE 1200V 75A 445W 7PMGA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FMG2G75US120 Specifications:
- MfrPart.: FMG2G75US120
- Mfr: onsemi
- Description: IGBT MODULE 1200V 75A 445W 7PMGA
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: -
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Configuration: Half Bridge
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 75 A
- Power-Max: 445 W
- Vce(on)(Max)@VgeIc: 3V @ 15V, 75A
- Current-CollectorCutoff(Max): 3 mA
- InputCapacitance(Cies)@Vce: -
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: 7PM-GA
- FMG2G75US120 onsemi (ON), IGBT MODULE 1200V 75A 445W 7PMGA, Discrete Semiconductor Products~Transistors - IGBTs - Modules
