FMG1G100US60L Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: 7PM-GA
- Description: IGBT MODULE 600V 100A 400W 7PMGA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FMG1G100US60L Specifications:
- MfrPart.: FMG1G100US60L
- Mfr: onsemi
- Description: IGBT MODULE 600V 100A 400W 7PMGA
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 100 A
- Power-Max: 400 W
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 100A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 10.84 nF @ 30 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: 7PM-GA
- FMG1G100US60L onsemi (ON), IGBT MODULE 600V 100A 400W 7PMGA, Discrete Semiconductor Products~Transistors - IGBTs - Modules
