FGY75T95SQDT Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 950V 75A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGY75T95SQDT Specifications:
- MfrPart.: FGY75T95SQDT
- Mfr: onsemi
- Description: IGBT 950V 75A
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Last Time Buy
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 950 V
- Current-Collector(Ic)(Max): 150 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.11V @ 15V, 75A
- Power-Max: 434 W
- SwitchingEnergy: 8.8mJ (on), 3.2mJ (off)
- InputType: Standard
- GateCharge: 137 nC
- Td(on/off)@25°C: 28.8ns/117ns
- TestCondition: 600V, 75A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): 259 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGY75T95SQDT onsemi (ON), IGBT 950V 75A, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGY75T95SQDT, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
onsemi (ON) Authorized Distributor | NHE is dedicated to providing first-quality, genuine onsemi components.
