FGY75T120SQDN Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 1200V 75A UFS
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGY75T120SQDN Specifications:
- MfrPart.: FGY75T120SQDN
- Mfr: onsemi
- Description: IGBT 1200V 75A UFS
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 150 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 1.95V @ 15V, 75A
- Power-Max: 790 W
- SwitchingEnergy: 6.25mJ (on), 1.96mJ (off)
- InputType: Standard
- GateCharge: 399 nC
- Td(on/off)@25°C: 64ns/332ns
- TestCondition: 600V, 75A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 99 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- FGY75T120SQDN onsemi (ON), IGBT 1200V 75A UFS, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGY75T120SQDN, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
