FGY75N60SMD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 600V 150A 750W POWER-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGY75N60SMD Specifications:
- MfrPart.: FGY75N60SMD
- Mfr: onsemi
- Description: IGBT 600V 150A 750W POWER-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 150 A
- Current-CollectorPulsed(Icm): 225 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 75A
- Power-Max: 750 W
- SwitchingEnergy: 2.3mJ (on), 770µJ (off)
- InputType: Standard
- GateCharge: 248 nC
- Td(on/off)@25°C: 24ns/136ns
- TestCondition: 400V, 75A, 3Ohm, 15V
- ReverseRecoveryTime(trr): 55 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- FGY75N60SMD onsemi (ON), IGBT 600V 150A 750W POWER-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
