FGY120T65SPD-F085 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 650V 240A 882W TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGY120T65SPD-F085 Specifications:
- MfrPart.: FGY120T65SPD-F085
- Mfr: onsemi
- Description: IGBT 650V 240A 882W TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 240 A
- Current-CollectorPulsed(Icm): 378 A
- Vce(on)(Max)@VgeIc: 1.85V @ 15V, 120A
- Power-Max: 882 W
- SwitchingEnergy: 6.8µJ (on), 3.5µJ (off)
- InputType: Standard
- GateCharge: 162 nC
- Td(on/off)@25°C: 53ns/102ns
- TestCondition: 400V, 120A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 123 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGY120T65SPD-F085 onsemi (ON), IGBT 650V 240A 882W TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGY120T65SPD-F085, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
